8TQ100PBF Schottky Rectifier, 8 A High frequency operation Low forward voltage drop 175 °C TJ operation

Product Categories

Anterwell Technology Ltd.

Contact Now

8TQ100PBF Schottky Rectifier, 8 A High frequency operation Low forward voltage drop 175 °C TJ operation

Name: 8TQ100PBF Schottky Rectifier 8 A High frequency operation Low forward voltage drop 175 C TJ operation
Brand: VISHAY
Price: 0.1 USD

Brand Name : VISHAY

Model Number : 8TQ100PBF

Certification : Original

Place of Origin : Original

MOQ : 5PCS

Price : USD0.1

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 10000PCS/DAY

Delivery Time : 1 DAY

Packaging Details : Contact us for more detail

Package : TO-220AC

VR : 60 V, 80 V, 100 V

IRMmax. : 7 mA at 125 °C

Diode variation : Single die

EAS : 7.5 mJ

IF(AV) : 8 A

Contact Now

Schottky Rectifier, 8 A

8TQ100PBF Schottky Rectifier, 8 A High frequency operation Low forward voltage drop 175 °C TJ operation FEATURES

• 175 °C TJ operation

• Low forward voltage drop

• High frequency operation

• High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance • Guard ring for enhanced ruggedness and long term reliability

• Compliant to RoHS Directive 2002/95/EC

• Designed and qualified according to JEDEC-JESD47

• Halogen-free according to IEC 61249-2-21 definition (-N3 only)

DESCRIPTION

The VS-8TQ... Schottky rectifier series has been optimized for low reverse leakage at high temperature. The proprietary barrier technology allows for reliable operation up to 175 °C junction temperature. Typical applications are in switching power supplies, converters, freewheeling diodes, and reverse battery protection.

PRODUCT SUMMARY
Package	TO-220AC
I_F(AV)	8 A
V_R	60 V,80 V,100 V
V_Fat I_F	0.58 V
I_RMMAX.	7 mA at 125°
T_JMAX.	175°
Diode variation	Single die
E_AS	7.5 mJ

8TQ100PBF Schottky Rectifier, 8 A High frequency operation Low forward voltage drop 175 °C TJ operation

MAJOR RATINGS AND CHARACTERISTICS
SYMBOL	CHARACTERISTICS	VALUES	UNITS
I_F(AV)	Rectangular waveform	8	A
V_RRM	Range	60 to 100	V
I_FSM	t_p = 5 μs sine	850	A
V_F	8 A_pk, T_J= 125 °C	0.58	V
T_J	Range	- 55 to 175	°C
