UF5402 Rectifier Diode 3 Amp Ultra Fast Recovery Rectifier 50 to 1000 Volts

Product Categories

Anterwell Technology Ltd.

Contact Now

Brand Name : MCC

Model Number : UF5402

Certification : Original Factory Pack

Place of Origin : Philippines

MOQ : 20

Price : Negotiate

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 20000

Delivery Time : 1

Packaging Details : please contact me for details

Average Forward Current : 3 A

Peak Forward Surge Current : 150A

Maximum Instantaneous Forward Voltage : 1.0V

Moisture Sensitivity : Level 1

Operating Temperature : -55°C to +150°C

Contact Now

Features

• Lead Free Finish/RoHS Compliant(Note 1)

UF5402 Rectifier Diode 3 Amp Ultra Fast Recovery Rectifier 50 to 1000 Volts ("P" Suffix designates RoHS Compliant. See ordering information)

• Epoxy meets UL 94 V-0 flammability rating

• Moisture Sensitivity Level 1

• Low Forward Voltage Drop and Low Leakage

• Ultra Fast Switching Speed For High Efficiency

Maximum Ratings

• Operating Temperature: -55°C to +150°C

• Storage Temperature: -55°C to +150°C

• Typical Thermal Resistance 20°C/W

MCC Catalog Number	Device Marking	Maximum Recurrent Peak Reverse Voltage	Maximum RMS Voltage	Maximum DC Blocking Voltage
UF5400	---	50V	35V	50V
UF5401	---	100V	70V	100V
UF5402	---	200V	140V	200V
UF5404	---	400V	280V	400V

Reverse Recovery Time Characteristic And Test Circuit Diagram

Notes:

1. Rise Time = 7ns max. Input impedance = 1 megohm, 22pF

2. Rise Time = 10ns max. Source impedance = 50 ohms

3. Resistors are non-inductive

Ordering Information :
