MAX4252EUA Electronics IC Chips Integrated Circuits IC Component

Anterwell Technology Ltd.
Contact Now

MAX4252EUA Electronics IC Chips Integrated Circuits IC Component

Brand Name : MAXIM

Model Number : MAX4252EUA

Certification : Original Factory Pack

Place of Origin : Original

MOQ : 100pcs

Price : Negotiation

Payment Terms : T/T, Western Union,PayPal

Supply Ability : 33000PCS

Delivery Time : 1 Day

Packaging Details : 3000/REEL

Temperature Range : -65°C to +150°C

Payment Term : T/T, Paypal, Western Union

Voltage : +6.0V to -0.3V

Current : ±50 mA

Package : SOP-8

Factory Package : 3000/REEL

Contact Now

MAX4252EUA Electronics IC Chips Integrated Circuits IC Component

UCSP, Single-Supply, Low-Noise, Low-Distortion, Rail-to-Rail Op Amps





Features

♦ Available in Space-Saving UCSP™, SOT23, and µMAX Packages

♦ Low Distortion: 0.0002% THD (1kΩ load)

♦ 400µA Quiescent Supply Current per Amplifier

♦ Single-Supply Operation from +2.4V to +5.5V

♦ Input Common-Mode Voltage Range Includes Ground

♦ Outputs Swing Within 8mV of Rails with a 10kΩ Load

♦ 3MHz GBW Product, Unity-Gain Stable (MAX4250–MAX4254) 22MHz GBW Product, Stable with AV ≥ 10V/V (MAX4249/MAX4255/MAX4256/MAX4257)

♦ Excellent DC Characteristics VOS = 70µV IBIAS = 1pA Large-Signal Voltage Gain = 116dB

♦ Low-Power Shutdown Mode: Reduces Supply Current to 0.5µA Places Outputs in a High-Impedance State

♦ 400pF Capacitive-Load Handling Capability



ABSOLUTE MAXIMUM RATINGS

Power-Supply Voltage (VDD to VSS)......................+6.0V to -0.3V

Analog Input Voltage (IN_+, IN_-)....(VDD + 0.3V) to (VSS - 0.3V)

SHDN Input Voltage....................................+6.0V to (VSS - 0.3V)

Output Short-Circuit Duration to Either Supply ..........Continuous Continuous Power Dissipation

(TA = +70°C) 5-Pin SOT23 (derate 7.1mW/°C above +70°C)...........571mW

8-Pin µMAX (derate 4.5mW/°C above +70°C) ............362mW

8-Pin SO (derate 5.88mW/°C above +70°C)...............471mW 8-Pin

UCSP (derate 4.7mW/°C above +70°C) ............379mW 10-Pin UCSP

(derate 6.1mW/°C above +70°C) ...........484mW

10-Pin µMAX (derate 5.6mW/°C above +70°C) ...........444mW

14-Pin SO (derate 8.33mW/°C above +70°C)..............667mW

Operating Temperature Range .........................-40°C to +125°C Junction Temperature......................................................+150°C

Storage Temperature Range .............................-65°C to +150°C

Lead Temperature (soldering, 10s) .................................+300°C

Bump Temperature (soldering) (Note 1) Infrared (15s) ........................+220°C

Vapor Phase (60s) ........................................................+215°C



Ordering Information

PART                            TEMP.                       RANGE PIN/BUMPPACKAGE                TOP MARK
MAX4249ESD       -40°C to +85°C                                  14 SO                                          —
MAX4249EUB       -40°C to +85°C                                  10 µMAX                                     —
MAX4250EUK-T     -40°C to +85°C                                 5 SOT23-5                                ACCI



MAX4252EUA Electronics IC Chips Integrated Circuits IC Component
