SS14-E3-61T Surface Mount Schottky Barrier Rectifier Low profile package for automated placement

Name: SS14E361T Surface Mount Schottky Barrier Rectifier Low profile package for automated placement
Brand: EXAR
Price: 0.1 USD

Brand Name : EXAR

Model Number : SP3203ECY-L

Certification : Original

Place of Origin : Original

MOQ : 5 PCS

Price : 0.1USD

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 10000PCS/DAY

Delivery Time : 1 day

Packaging Details : contact us for more details

Voltage : +3.0V to +5.5V

Temperature : 260 °C

Application : high frequency inverters

Features : Guardring for overvoltage protection

Description : High surge capability

Type : Barrier Rectifier

Contact Now

SS14-E3-61T Surface Mount Schottky Barrier Rectifier

FEATURES

• Low profile package

• Ideal for automated placement

• Guardring for overvoltage protection

• Low power losses, high efficiency

• Low forward voltage drop

• High surge capability

DO-214AC (SMA)

• Meets MSL level 1, per J-STD-020, LF maximum

peak of 260 °C

• Solder dip 260 °C, 40 s

• Component in accordance to RoHS 2002/95/EC

and WEEE 2002/96/EC

TYPICAL APPLICATIONS

For use in low voltage, high frequency inverters,

freewheeling, dc-to-dc converters, and polarity

protection applications.

1.0 A

PRIMARY CHARACTERISTICS SS14-E3-61T Surface Mount Schottky Barrier Rectifier Low profile package for automated placement

Epoxy meets UL 94V-0 flammability rating

Terminals:

Matte tin plated leads, solderable per

J-STD-002 and JESD22-B102

E3 suffix for consumer grade, meets JESD 201 class

1A whisker test, HE3 suffix for high reliability grade

(AEC Q101 qualified), meets JESD 201 class 2

whisker test

Polarity:

Color band denotes the cathode end

PREFERRED P/N	UNIT WEIGHT (g)	PREFERRED PACKAGE CODE	BASE QUANTITY	DELIVERY MODE
SS14-E3/61T	0.064	61T	1800	7" diameter plastic tape and reel
SS14-E3/5AT	0.064	5AT	7500	13" diameter plastic tape and reel
SS14HE3/61T⁽¹⁾	0.064	61T	1800	7" diameter plastic tape and reel
SS14HE3/5AT⁽¹⁾	0.064	5AT	7500	13" diameter plastic tape and reel
