R3060P2 30A 600V Stealth⑩ Signal Schottky diode , double diode model

Name: R3060P2 30A 600V Stealth Signal Schottky diode double diode model
Brand: FAIRCHILD
Price: 1 USD

Brand Name : FAIRCHILD

Model Number : R3060P2

Certification : Original Factory Pack

Place of Origin : Original

MOQ : 50pcs

Price : negotiation

Payment Terms : T/T, Western Union,PayPal

Supply Ability : 5200PCS

Delivery Time : 1 day

Packaging Details : please contact me for details

Soft Recovery : . tb / ta > 1.2

Fast Recovery : . trr < 35ns

Operating Temperature : 175oC

Reverse Voltage : 600V

Avalanche Energy Rated : /

Contact Now

ISL9R3060G2, ISL9R3060P2 30A, 600V Stealth™ Diode

R3060P2 30A 600V Stealth⑩ Signal Schottky diode , double diode model

General Description

The ISL9R3060G2 and ISL9R3060P2 are Stealth™ diodes optimized for low loss performance in high frequency hard switched applications. The Stealth™ family exhibits low reverse recovery current (IRRM) and exceptionally soft recovery under typical operating conditions.

This device is intended for use as a free wheeling or boost diode in power supplies and other power switching applications. The low IRRM and short ta phase reduce loss in switching transistors. The soft recovery minimizes ringing, expanding the range of conditions under which the diode may be operated without the use of additional snubber circuitry. Consider using the Stealth™ diode with an SMPS IGBT to provide the most efficient and highest power density design at lower cost.

Formerly developmental type TA49411.
