Electronics Programmable IC Chips Isolated RS 485 Transceiver ADM2483BRWZ

Brand Name : A D

Model Number : ADM2483BRWZ

Certification : Original Factory Pack

Place of Origin : Malaysia

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T, Western Union,PayPal

Supply Ability : 2000PCS

Delivery Time : 1 Day

Packaging Details : please contact me for details

Voltage : 9V-14Vl

Shipment : DHL, Fedex, TNT, EMS etc

Package : SOP-16

Main Line : Ic,module,transistor,diodes,capacitor,resistor etc

Operating Temperature Range : −40°C to +85°C

Storage Temperature Range : −55°C to +150°C

Contact Now

Electronics Programmable IC Chips Isolated RS 485 Transceiver ADM2483BRWZ

Isolated RS-485 Transceiver ADM2483BRWZ AD Original Electronics Chip

FEATURES

RS-485 transceiver with electrical data isolation Complies with ANSI TIA/EIA RS-485-A and ISO 8482: 1987(E) 500 kbps data rate Slew rate-limited driver outputs Low power operation: 2.5 mA max Suitable for 5 V or 3 V operations (VDD1) High common-mode transient immunity: >25 kV/μs True fail-safe receiver inputs Chatter-free power-up/power-down protection 256 nodes on bus Thermal shutdown protection Safety and regulatory approvals UL recognition: 2500 Vrms for 1 minute per UL 1577 CSA Component Acceptance Notice #5A VDE Certificate of Conformity DIN EN 60747-5-2 (VDE 0884 Rev. 2): 2003-01 DIN EN 60950 (VDE 0805): 2001-12; EN 60950: 2000 VIORM = 560 V peak Operating temperature range: −40°C to +85°C APPLICATIONS Low power RS-485/RS-422 networks Isolated interfaces Building control networks Multipoint data transmission systems

ABSOLUTE MAXIMUM RATINGS

Parameter

Rating

VDD1

VDD2

Digital Input Voltage (DE, RE, TxD)

Digital Output Voltage RxD

Driver Output/Receiver Input Voltage

ESD Rating: Contact (Human Body Model) (A, B Pins)

Operating Temperature Range

Storage Temperature Range

Average Output Current per Pin

Thermal Impedance

Lead Temperature

Soldering (10 sec)

Vapor Phase (60 sec)

Infrared (15 sec)

−0.5 V to +7 V

−0.5 V to +6 V

−0.5 V to VDD1 + 0.5 V

−9 V to +14 V

±2 kV

−40°C to +85°C

−55°C to +150°C

−35 mA to +35 mA θJA

73°C/W

260°C

215°C

220°C
