FEATURES
• Small foot print, surface mountable
• Low profile
• Very low forward voltage drop
• High frequency operation
• Guard ring for enhanced ruggedness and long term reliability
• Common cathode
• Designed and qualified for industrial level
DESCRIPTION
The 20CJQ030 surface mount Schottky rectifier series has been designed for applications requiring very low forward drop and very small foot prints. Typical applications are in portables, switching power supplies, converters, automotive system, freewheeling diodes, battery charging, and reverse battery protection.
| MAJOR RATINGS AND CHARACTERISTICS |
| SYMBOL | CHARACTERISTICS | VALUES | UNITS |
| IF(AV) | Rectangular waveform | 2 | A |
| VRRM | | 30 | V |
| IFSM | tp = 5 µs sine | 400 | A |
| VF | 1 Apk, TJ = 125 °C (per leg) | 0.42 | V |
| TJ | Range | - 55 to 150 | °C |
