BZV85C7V5 Rectifier Diode DO-41 SILICON PLANAR POWER ZENER Diode

Name: BZV85C7V5 Rectifier Diode DO41 SILICON PLANAR POWER ZENER Diode
Brand: anterwell
Price: 1 USD

Brand Name : anterwell

Model Number : BZV85C7V5

Certification : new & original

Place of Origin : original factory

MOQ : 10pcs

Price : Negotiate

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 5000pcs

Packaging Details : Please contact me for details

Power Dissipation : 1W

Junction Temperature : 200 °C

Storage Temperature Range : - 65°C to + 200°C

Datasheet : Contact us for more details

Contact Now

BZV85C7V5 DO-41 SILICON PLANAR POWER ZENER Diode

Features

Silicon Planar Power Zener Diodes for use in stabilizing and clipping circuits with high power rating. The Zener voltage are graded according to the international E 24 standard. Other voltage tolerances and higher Zener voltages upon request.

BZV85C7V5 Rectifier Diode DO-41 SILICON PLANAR POWER ZENER Diode

DIMENSIONS
DIM	inches		mm		Note
DIM	Min	Max	Min	Max	Note
A	--	0.169	---	4.3
B	--	0.110	---	2.8
C	--	0.031	---	0.8
D	1.102	--	28.0

Absolute Maximum Ratings (Ta =25 )

	Symbols	Values	Units
Zener current see Table "Characteristics"
Power dissipation at Tamb=25°C	Ptot	1 1)	W
Junction temperature	Tj	200	°C
Storage temperature range	TS	-65 to +200	°C

Note: (1) Valid provided that leads at a distance of 8 mm from case are kept at ambient temperature

Characteristics at Tamb=25°C

	Symbols	Min	Typ.	Max.	Units
Thermal resistance junction to ambient Air	RthA	--	--	170 1)	K/W
Forward voltage at IF =200mA	VF	--	--	1.2	V

BZV85C7V5 Rectifier Diode DO-41 SILICON PLANAR POWER ZENER Diode
