BT136-600E Thyristor Product Catalog Triacs Sensitive Gate High Sensitivity

Product Categories

Anterwell Technology Ltd.

Contact Now

BT136-600E Thyristor Product Catalog Triacs Sensitive Gate High Sensitivity

Brand Name : ISC

Model Number : BT136-600E

Certification : Original Factory Pack

Place of Origin : Philippines

MOQ : 20

Price : Negotiate

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 20000

Delivery Time : 1

Packaging Details : please contact me for details

Features : ·With TO-220AB package

Features2 : ·Glass passivated, sensitive gate triacs in a plastic envelope

Features3 : intended for use in general purpose bidirectional switching and phase control applications, where high sensitivity is required in all four quadrants.

Features4 : Repetitive peak off-state voltage 600 V

Features5 : Repetitive peak off-state voltage 600 V

Contact Now

BT136-600E Thyristor Product Catalog Triacs Sensitive Gate High Sensitivity

Features

· With TO-220AB package BT136-600E Thyristor Product Catalog Triacs Sensitive Gate High Sensitivity

· Glass passivated, sensitive gate triacs in a plastic envelope,

intended for use in general purpose bidirectional

switching and phase control applications,

where high sensitivity is required in all four quadrants.

 QUICK REFERENCE DATA

SYMBOL	PARAMETER	VALUE	UNIT
VDRM	Repetitive peak off-state voltage	600	V
VRRM	Repetitive peak off-state voltage	600	V
T_(AV)	Average on-state current	4	A
I_TSM	Non-repetitive peak on-state current	25	A
Tstg	Storage temperature	-45～150	℃
T_j	Operating junction temperature		℃

BT136-600E Thyristor Product Catalog Triacs Sensitive Gate High Sensitivity

Product Tags:

multi emitter transistor

silicon power transistors

BT136-600E Thyristor Product Catalog Triacs Sensitive Gate High Sensitivity Images
